Carbon And Glass Fiber Pultruded Profiles
Carbon And Glass Fiber Pultruded Profiles
- Features
- Peel Ply Cover
- High Rigidity
- Low Porosity
- Wind Turbine Blade
- High Fiber Straightness
Description
Carbon fiber and glass fiber/epoxy resin pultruded profiles are manufactured through a pultrusion process. A continuously processed composite material with high fiber content, high performance and low cost. In the manufacturing process, the carbon fiber bundle is formed through a special impregnation and curing process. Compared with other composite materials processing, the high fiber straightness achieved by pultrusion can provide excellent mechanical properties in the laminated structure.PRODUCT SPECIFICATIONS
| Resin | Fiber | Specification | Fiber Volume Content (%) | |
|---|---|---|---|---|
| Width (mm) | Thickness (mm) | |||
| Epoxy Resin | Carbon Fiber | 50-200 | 1-8 | 58-72 |
| Glass Fiber | ||||
| Vinyl Ester Resin | Carbon Fiber | |||
| Glass Fiber | ||||
MECHANICAL PROPERTIES
| Properties | Unit | Product Types |
Test Standard
|
||
|---|---|---|---|---|---|
|
Carbon Fiber / Epoxy
|
Glass Fiber / Epoxy
|
||||
| Fiber Volume Content | % | 60% | 65% | 70% | - |
| 0°Tensile Strength | MPa | 1700 | 2000 | 1500 | ISO 527-5 |
| 0°Tensile Modulus | GPa | 135 | 150 | 65 | |
| 0° Compressive Strength | MPa | 1050 | 1400 | 1500 | ISO 14126 |
| 0°Compressive Modulus | GPa | 130 | 145 | 60 | |
| 0°Flexural Strength | MPa | 1200 | 1350 | 1300 | ISO 14125 |
| 0°Flexural Modulus | GPa | 140 | 145 | 60 | |
- Note: The above information is for general reference only and cannot be used as a guarantee.
MAIN APPLICATION AREAS
Wind Turbine Blade
Construction
